Pad Mounted Transformers

NEW | REWOUND | RECONDITIONED

UTB sells Pad Mounted Transformers in North America for a variety of applications.

Pad Mounted Transformers

Pad Mounted Distribution Transformers are used in the Power Grid to step down or step up voltage depending on the specific need. Padmounted transformers are fed from underground and typically contain Mineral Oil or Natural Ester Fluid. These transformers usually range from 15 KVA up to 5000 KVA and have a primary voltage between 2400 – 34500 volts, but can also be designed up to 10,000 kVA and 69,000 volts.


Pad Mounted transformers are used in a wide range of industries, including; power generation, utility, industrial, mining, oil & gas, as well as government.

We deal in units from 50kVA to 10,000kVA. Whatever your project need is, we are certain to have a solution.

STANDARD SPECS

• Tamper-Proof Cabinet
• Munsell Green Paint
• Dead Front or Live Front
• Loop Feed or Radial Feed
• Mild Steel Tank & Cabinet
• Non PCB Mineral Oil
• De-Energized Tap Changer
• Bayonet Fusing
• Pressure Relief Device
• Liquid Temp Gauge
• Aluminum Windings

OPTIONAL SPECS

• FR3 Fluid
• Cooling Packages
• Electro Static Shield
• 2 or 4 Position Switch
• All Copper Windings
• Stainless Steel Tank & Cabinet
• Meter Socket
• Skid Mounted
• 55/65 Degree C Temperature Rise
• Custom Paint Colors
